AC compressor FORD Transit Mk4 Platform/Chassis (VE83) 4HD 2.5TD 75 HP
<
1
2
3
4
5
>
>>
Product ID: TSP0159376
- Compressor Oil: PAG 46
- Manufacturer Restriction: Delphi
- Compressor ID: Sanden / Scroll TRS0
- Belt Pulley Ø [mm]: 95
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil
- Clutch ID: PV6
- Quality: Delphi inside
- Vehicle type: Transit 120
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 89205
- Compressor Oil: PAG 46
- Oil Fill Quantity [ml]: 200
- Compressor ID: FS10
- Belt Pulley Ø [mm]: 125
- Refrigerant: R134a
- Voltage [V]: 12
- Inlet Ø [mm]: 16
- Outlet Ø [mm]: 13
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil, with magnetic clutch, without diode
- Number of grooves: 6
- Capacity Compressor [cc]: 200
- Connector Shape: rectangular
- Number of pins: 2
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 1 986 AD1 192
- Compressor Oil: PAG 46
- Oil Fill Quantity [ml]: 180
- Belt Pulley Ø [mm]: 113
- Refrigerant: R134a
- Voltage [V]: 12
- Inlet Ø [mm]: 16,4
- Outlet Ø [mm]: 13
- Supplementary Article / Supplementary Info Info 2: with seal ring, with mounting manual
- for OE number: 5211564
- Number of grooves: 6
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 89251
- Climate Zones: for hot climate zones
- Vehicle type: Transit 190
- Manufacturer Restriction: FORD
- Compressor Oil: PAG 46
- Oil Fill Quantity [ml]: 160
- Compressor ID: FS10
- Belt Pulley Ø [mm]: 143
- Refrigerant: R134a
- Voltage [V]: 12
- New Part
- Inlet Ø [mm]: 17
- Outlet Ø [mm]: 14
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil
- Number of grooves: 6
- Capacity Compressor [cc]: 170
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: TSP0159103
- Compressor Oil: PAG 46
- Manufacturer Restriction: Delphi
- Compressor ID: Visteon FS10
- Belt Pulley Ø [mm]: 114
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil
- Clutch ID: PV6
- Quality: Delphi Inside
- Vehicle type: Transit 120
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 447K0154
- Compressor Oil: PAG 46
- Compressor ID: FS10-170
- Belt Pulley Ø [mm]: 115
- Refrigerant: R134a
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil
- Number of grooves: 6
- Operating voltage [V]: 12
- Capacity Compressor [cc]: 170
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: ACP 153 000S
- Compressor Oil: PAG 46
- Manufacturer Restriction: Hanon
- Compressor ID: FS10-170
- Belt Pulley Ø [mm]: 115
- Number of ribs: 6
- Refrigerant: R134a
- Voltage [V]: 12
- Pulleys: with V-ribbed belt pulley
- Supplementary Article / Supplementary Info Info 2: with seal ring
- Connector type: H/PAD
- Packaging height [cm]: 21,00
- Packaging length [cm]: 18,5
- Packaging width [cm]: 27,50
- Number of grooves: 6
- Supplementary Article / Supplementary Info: without oil drain plug
- Net Weight [g]: 6318
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
free delivery
Product ID: ACP174
- Compressor Oil: PAG 46
- Manufacturer Restriction: VISTEON FS-10
- Oil Fill Quantity [ml]: 205
- Belt Pulley Ø [mm]: 143
- Refrigerant: R134a
- Number of mounting bores: 4
- Number of grooves: 6
- Supplementary Article / Supplementary Info: with gaskets/seals
- Net weight [kg]: 6,7
- Condition: Remanufactured
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Core exchange £ 42,20 core charge (incl. 20% VAT) is NOT included The core charge will be refunded if you return the old spare part.
Details
Product ID: 32085
- Compressor Oil: PAG 46
- Manufacturer Restriction: VISTEON-EQUIVALENT
- Oil Fill Quantity [ml]: 205
- Compressor ID: FS10-170
- Belt Pulley Ø [mm]: 145
- Voltage [V]: 12
- Pulleys: with V-ribbed belt pulley
- Supplementary Info: EASY FIT
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil, with seal ring
- Quality: OE-EQUIVALENT
- Number of grooves: 6
- Connector Shape: rectangular
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 89059
- Compressor Oil: PAG 46
- Oil Fill Quantity [ml]: 200
- Compressor ID: FS10
- Belt Pulley Ø [mm]: 144
- Refrigerant: R134a
- Voltage [V]: 12
- Inlet Ø [mm]: 16
- Outlet Ø [mm]: 13
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil, with magnetic clutch, without diode
- Number of grooves: 6
- Capacity Compressor [cc]: 200
- Connector Shape: rectangular
- Number of pins: 2
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 89046
- Compressor Oil: PAG 100
- Oil Fill Quantity [ml]: 160
- Compressor ID: FS10
- Belt Pulley Ø [mm]: 114
- Refrigerant: R134a
- Voltage [V]: 12
- Inlet Ø [mm]: 17
- Outlet Ø [mm]: 14
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil, with magnetic clutch, without diode
- Number of grooves: 6
- Capacity Compressor [cc]: 170
- Number of pins: 2
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
Product ID: 32110
- Compressor Oil: PAG 46
- Manufacturer Restriction: VISTEON-EQUIVALENT
- Oil Fill Quantity [ml]: 190
- Compressor ID: FS10-170
- Belt Pulley Ø [mm]: 115
- Voltage [V]: 12
- Product line: EASY FIT
- Supplementary Article / Supplementary Info Info 2: with PAG compressor oil, with seal ring
- Quality: OE-EQUIVALENT
- Number of grooves: 6
- Condition: New
IMPORTANT
When replacing the air compressor, the has to be replaced and the system flushed! Otherwise, the warranty will not be valid!
Details
AC compressor Transit Mk4 Platform/Chassis (VE83)
- Transit Mk4 Platform/Chassis VE83 2.5 TD (EME/L/S, ENE/L/S) 101 HP 08.1994 - 03.2000
- Transit Mk4 Platform/Chassis VE83 2.5 DI (EME/L/S, ENE/L/S) 76 HP 08.1994 - 03.2000
- Transit Mk4 Platform/Chassis VE83 2.5 TD (EME/L/S, ENE/L/S) 85 HP 08.1994 - 03.2000
- Transit Mk4 Platform/Chassis VE83 2.5 DI (EML/S, ENL/S) 69 HP 08.1994 - 03.2000
- Transit Mk4 Platform/Chassis VE83 2.5 DI (EML, ENE/L) 116 HP 05.1999 - 03.2000
- Transit Mk4 Platform/Chassis VE83 2.0 (EME/L/S, ENE/L/S) 114 HP 08.1994 - 03.2000
AC compressor FORD TRANSIT
- Air con compressor FORD Transit Mk6 Box (V347, V348, FA)
- Air con compressor FORD Transit Mk7 Van (V363, FCD, FDD)
- Air con compressor FORD TRANSIT Box (FA_ _)
- Air con compressor FORD Transit Mk6 Platform / Chassis (V347, V348, FM, FN, FF)
- Air con compressor FORD Transit Mk7 Platform / Chassis (V363, FED, FFD)
- Air con compressor FORD Transit Mk6 Bus (V347, V348, FD, FB, FS, FZ, FC)
