Product ID: 24.0218-0023.1
- Outer brake drum diameter [mm]: 220,0
- Inner brake drum diameter [mm]: 180,0
- Inner brake drum height [mm]: 48,0
- Number of Holes: 5
- Bolt Hole Circle Ø [mm]: 112,0
- Total brake drum height [mm]: 57,5
- max. brake drum reboring dimension [mm]: 181,2
- Support plate diameter [mm]: 67,0
- MAPP code available
- Bore Diameter [mm]: 13,3
- Test Mark: E1 90R-02D0324/1876
- Condition: New
Details
Product ID: 24.0226-0001.1
- Outer brake drum diameter [mm]: 300,0
- Inner brake drum diameter [mm]: 260,0
- Inner brake drum height [mm]: 64,0
- Number of Holes: 5
- Bolt Hole Circle Ø [mm]: 130,0
- Total brake drum height [mm]: 83,0
- max. brake drum reboring dimension [mm]: 261,5
- Support plate diameter [mm]: 85,0
- MAPP code available
- Bore Diameter [mm]: 15,0
- Condition: New
Details
Product ID: 24.0223-0009.1
- Outer brake drum diameter [mm]: 266,0
- Inner brake drum diameter [mm]: 230,0
- Inner brake drum height [mm]: 43,0
- Number of Holes: 5
- Bolt Hole Circle Ø [mm]: 130,0
- Total brake drum height [mm]: 73,0
- max. brake drum reboring dimension [mm]: 231,0
- Support plate diameter [mm]: 85,0
- MAPP code available
- Bore Diameter [mm]: 15,0
- Condition: New
Details
Product ID: 24.0225-4003.1
- Outer brake drum diameter [mm]: 272,0
- Inner brake drum diameter [mm]: 254,0
- Inner brake drum height [mm]: 65,0
- Number of Holes: 5
- Bolt Hole Circle Ø [mm]: 140,0
- Total brake drum height [mm]: 93,0
- max. brake drum reboring dimension [mm]: 255,0
- Support plate diameter [mm]: 90,0
- MAPP code available
- Bore Diameter [mm]: 17,2
- Condition: New
Details
